Ectrical Characteristics

 Rated Voltage

AC/DC60V

 Rated Current

Power 20A Signal 2A

Withstanding Voltage

500V

 Insulation Resistance

>20MΩ

 Contact Resistance

<10mΩ

 Mechanical Characteristics

 Mating Cycles

200 cycles

Insertion and Pull

Insertion  :30Nmax

Pull :/

 Environment Characteristics

 Protection Level

IP67

 Operation Temperature

-25°C~+80°C

 Other Specification

 Maximum Diameter

10mm

 Contact Material

tinned copper

 Cable Spec.

Power   13AWG

Signal   24AWG
