Ectrical Characteristics

 Rated Voltage   AC/DC60V

Rated Current   Power 20A

Withstanding Voltage   500V

Insulation Resistance   >20MΩ

Contact Resistance      <10mΩ

 Mechanical Characteristics

 Mating Cycles   200 cycles

Insertion and Pull

Insertion :100Nmax

Pull : 50N min

 Environment Characteristics

 Protection Level    /

Operation Temperature     -25°C~+80°C

Other Specification

 Maximum Diameter     10mm

Mating Length     35mm

Contact Material  tinned copper

 Cable Spec.

Power     14AWG
