Ectrical Characteristics

 Rated Voltage   AC/DC60V

 Rated Current    Power 30A Signal 2A

Withstanding Voltage     500V

Insulation Resistance    >20MΩ

 Contact Resistance      <10mΩ

 Mechanical Characteristics

 Mating Cycles     3000 cycles

Insertion and Pull

Insertion :100Nmax

Pull : 50N min

 Environment Characteristics

 Protection Level     IP67

 Operation Temperature    -25°C~+80°C

 Other Specification

 Maximum Diameter    10mm

 Contact Material    nickel-plated copper

Cable Spec.

Power    14AWG

Signal    24AWG
